GX SERIES 1 Rigid Solar Panels Are Designed For RV Traveling And Meet All The Needs Of RV Campers, With Green Power Supplying The Basic Electrical Load And Meeting The Power Needs Of RV Life.
With A Conversion Efficiency Of Up To 22.70%, The GX SERIES 1 Solar Panel Kits For RV Offer You A More Comfortable And Secure RV Living Environment With Its High Charging Efficiency And Short And Almost Silent Working Sound.
Versatility
High Transparency
Durable And Robust
High Safety
High Effciency
Model | 100w | 120w | 135w | 150w | 180w |
| Cell Efficiency | 22.70% | ||||
| Max Power Voltage | 23.9V | 18.8V | 20.5V | 22.8V | 20.5V |
| Max Power Current | 4.19A | 6.39A | 6.59A | 6.58A | 8.79A |
| Open Circuit Voltage | 28.0V | 22.0V | 24.0V | 26.7V | 24.0V |
| Short Circuit Current | 4.39A | 6.70A | 6.91A | 6.91A | 9.22A |
| Cell Type | Mono Cell | Mono Cell | Mono Cell | Mono Cell | Mono Cell |
| Solar Cells | 3*14 | 3*11 | 3*12 | 4*10 | 4*18 |
| Cell Dimension | 182*60.67mm | 182*91mm | 182*91mm | 182*91mm | 182*60.67mm |
| Weight | - | ||||
| Module Dimension | 1005*590*55mm | 1150*590*55mm | 1245*590*55mm | 1060*770*55mm | 1260*770*55mm |
| Frame | Silver Aluminium Frame | ||||
| Maximum System Voltage | DC 1000 | ||||
| Back Sheet | White PET | ||||
| Output Power Tolerance | ±3% | ||||
| Operating Temperature | -40℃-+85℃ | ||||
| Material | Glass | ||||
| Warranty | 10 Years | ||||
| Customize Service | ABAH TECH Offer Customize Service,Please Refer To Our Website Or Ask ABAH TECH Workers For More Sizes And The Latest Parameters. | ||||
