3 Axle 56 CBM LPG Liquid Propane Gas Bullet Tank Semi Truck Tanker Trailer
LPG equipment, which include LPG tanker truck, semi trailer, storage tanker, LPG container or LPG skid station could be used for transport or storing Liquid petroleum gas, propane, propylene, liquid ammonia, dimethyl ether and methanol, butadiene, isobutane, epoxy ethane, methylamine, etc.LPG tank skid station is made of bracket, 100% X-ray radiographic tested tanker, gas dispenser, pump, flow meter, pipeline system. It could be filling gas for the other equipment at anywhere.
ASME and ISO manufacture standard are both available.
Specifications
| Tanker trailer description |
| Overall dimension | 12700*2500*3975 mm |
| GVW | 39000kg |
| Curb weight | 15480kg |
| Wheelbase | 6865+1310+1310mm |
| Axles | BPW 12T*3 sets |
| Suspension | Mechanical |
| Landing leg | 28T JOST |
| Tire specification | 12.00R22.5 |
| Tire quantity | 12+1pcs |
| Tanker description |
| Tanker capacity | 56M3 |
| Filling medium | LPG |
| Filling density | 0.42kg/m3 |
| Loading weight | 23520kg |
| Tanker material | Carbon steel Q345R (Optional: Q370R, Q420R, Q470R) |
| Thickness | Tanker body | 12mm |
| End cover | 12mm |
| Tank dimension (diameter*thickness*length) | 2450×12*12340 |
| Designed temperature | 50ºC |
| Designed pressure | 1.61Mpa |
| Testing water pressure | 2.10MPa |
| Air tight test pressure | 1.61Mpa |
| Heat treatment | Wholly get rid of stress |
| Corrosion allowance | 1.0mm |
| Use Years | Ten years |
| Standard configuration | Equipped with double valve box and toolbox Equipped with double Emergency Cut-off Valve. Equipped with single pipe liquid out. Equipped with loading and unloading on each side. Equipped with safe valve, liquid level meter, thermometer, emergency cutting valve, , gas phase,liquid phase. |
